EDA94 Electric Cylinder

Engineered Positioning for Automation Builders

The EDA94 electric cylinder is positioned as a precision motion module for machine builders, integrators, and maintenance teams that need dependable thrust and repeatability without pneumatic infrastructure. As an electric cylinder actuator, it supports push/pull tasks where controllable motion, clean operation, and predictable life are required for production equipment. Our design emphasizes installation adaptability: both threaded and external thread interfaces, plus multiple mounting approaches, help standardize across stations while reducing redesign time. For projects constrained by envelope size, the fold-back configuration minimizes overall length, enabling integration into compact frames, guarding, and enclosed tooling. For longer strokes, the straight-line option fits applications that need reach while keeping cylinder size efficient.

Material Hardness and Space-Optimized Mechanics

Built from 6061 aluminum alloy with surface hardness up to 13, the EDA94 electric linear actuator is engineered for scratch, wear, and dirt resistance in industrial duty cycles. The cylinder body is optimized for durability where sliding contact, airborne particulates, and frequent handling can degrade typical housings. Two mechanical layouts are available to match design targets: a fold-back architecture for short overall length and a straight-line architecture to achieve longer stroke demands with a smaller overall cylinder size. Both threaded and external thread styles simplify fixture design and allow fast replacement without re-machining mounts. As a servo electric cylinder ready mechanical platform, it supports precise positioning when paired with appropriate drive and control selections, enabling repeatable linear motion within tight installation constraints.

Practical Value in Uplifts from Pneumatic to Electric

In production lines and robotic subassemblies, the EDA94 electric cylinder actuator enables measurable gains in controllability, noise reduction, and maintenance planning versus air-driven solutions, especially where position profiles and intermediate stops matter. It is well suited for automation cells requiring stable linear strokes for pressing, indexing, clamping, diverting, and alignment tasks, while its wear-resistant housing supports long-term uptime in mixed-contamination environments. For retrofit programs, the compact fold-back build helps fit legacy machine envelopes, and the straight-line option supports extended travel upgrades without oversizing the cylinder body. Where higher loading margins or rigid setups are requested, the EDA94 can be configured as a heavy duty electric cylinder solution within the system’s mechanical and drive limits, improving throughput stability and reducing unplanned stoppages.

Structural Integration and Installation Flexibility

Our EDA94 electric cylinder is designed around mechanical adaptability to accelerate engineering and commissioning. The availability of threaded and external thread interfaces supports different bracket standards, clevis concepts, and machine-side fastening practices, helping reduce custom adapter plates across product variants. Multiple installation methods allow the same electric cylinder actuator platform to be deployed in horizontal, vertical, or constrained orientations while maintaining service access. The fold-back design shortens overall length for dense machine layouts, and the straight-line design provides longer stroke capability with a smaller overall cylinder size—useful when tool clearance is tight. With a 6061 aluminum alloy body and hardened surface, the structure remains robust under frequent handling and in abrasive environments, supporting consistent alignment over long runs.

Operational Performance, Serviceability, and User Value

For operations teams, the EDA94 electric linear actuator delivers predictable mechanical behavior that supports stable process windows and repeatable positioning when paired with appropriate control. The hardened, dirt-resistant surface reduces cosmetic and functional degradation in real shop-floor conditions, which improves maintainability and helps preserve sealing and fit. Compact geometry can shorten cable routing and simplify guarding, while standardized mounting features reduce replacement time during planned maintenance. In applications requiring fine motion control and synchronized axes, the platform can be implemented as a servo electric cylinder, enabling smoother motion profiles and better process consistency than on/off actuation. Where applications call for higher stiffness and load margin, configuring the system as a heavy duty electric cylinder approach supports uptime goals by minimizing deflection and reducing adjustment frequency.

Use Scenarios

Automated Assembly Line Pressing and Positioning Stations

In automated assembly lines, the EDA94 electric cylinder is deployed for controlled pressing, part seating, and fixture positioning where repeatability and traceability are required. The actuator provides stable linear motion for tasks such as connector insertion, bearing placement, or stop-to-stop indexing, supporting cycle-time targets without the variability of compressed air supply. Its 6061 aluminum body with hardened surface improves resistance to scratches and debris common around feeders and conveyors, reducing wear-related maintenance. Using the electric cylinder actuator with threaded or external thread mounting simplifies station standardization and rapid swap-outs. When paired with closed-loop drives, it can function as a servo electric cylinder to execute multi-step force/position profiles, integrating cleanly with PLC motion modules and safety interlocks for compliant, production-ready automation.

Compact Retrofits in Space-Limited Machine Upgrades

During retrofit projects on legacy equipment, the EDA94 electric linear actuator supports modernization where space and mounting constraints typically block conversion from pneumatic cylinders. The fold-back design shortens overall length, helping fit inside existing machine frames, guarding, or tool carriages while maintaining necessary stroke for clamps, diverters, or alignment slides. Multiple installation methods and dual thread interface options enable engineers to reuse existing brackets with minimal rework, reducing downtime during commissioning. In environments with coolant mist, dust, or frequent handling, the hardened aluminum surface improves durability and keeps surfaces cleaner, supporting long service intervals. For higher load requirements—such as replacing oversized air cylinders on fixtures—the retrofit can be engineered as a heavy duty electric cylinder solution, delivering more consistent motion and easier integration into diagnostics and preventive maintenance workflows.

FAQ

1.Why are you choose us? KNK is a Hi-tech enterprise specializing in linear modules, linear rails, industrial manipulators, etc., integrating R&D,production and sales, "Specialized and New Enterprise"

2.What can you purchase from us? A one-stop procurement platform for automation products, including linear modules, guide rails, circular line modules, linear motors, PPU robotic arms, electric push cylinders, etc.

3.In Which Industries Can our Product be Applied? All industries of industrial automation equipment, such as 3D printing, food packaging, dispensing machines, conveying and feeding, laser equipment, industrial automation, vending machines, etc.

4.Customization Process? Consult customer service, determine parameters, communicate quotations, refine communication, confirm drawing plans, confirm production, product testing, shipping acceptance, installation guidance, after-sales service.

5.How About the Price? Because most products are customized, the final quotation is determined based on the complete description, size, material,quantity of the product you need.
